led shop light bulbs How to Wire a Hanging Light Fixture to a Wall Outlet

by:Leimove     2019-05-24
led shop light bulbs How to Wire a Hanging Light Fixture to a Wall Outlet
Hanging fixtures with a zipper switch can be connected to any available circuit, including a nearby wall socket, provided that the fixture does not overload the Circuit of the nearby wall socket.In order to hard connect the hanging fixture to the wall outlet, you need to enter the attic above the ceiling where the lamp is installed.If you have attic access, you can complete the whole project in a few hours with some basic hand tools.Turn off the circuit breaker and supply power to the power outlet where you want to hardwire the hanging lights.Loosen the screw with a flat head screwdriver and remove the plate cover.Hold a non-Connect the electrical tester to the black line on the side of the socket.If the light on the tester is on, the socket is still hot.Turn off other circuit breakers or main circuit breakers in the House and continue testing until the lights are no longer on.Loosen the top and bottom screws that mount the socket to the outlet box and pull the socket out of the box as much as possible.Loosen the wire clip on the back of the outlet and knock off the wire entry hole on the box next to the hole in the wire clip.Climb into the attic and find the wall head right above the vent.Drill a 5/8-An inch hole through the head can enter the wall below.Put the fish belt into the hole and guide the fish belt into the wire inlet hole on the back of the outlet box.Take the exit back to the room and pull 12 inch of the fish belt through the hole in the exit box.Overlap 4 inch of the end of a roll of 14/2 (with ground) cable at the end of the fish belt and wrap the tape at the intersection to fix the two together.Go back to the attic and gently pull the fish band until the wire goes through the hole.Open the electronic tape and separate the fish tape from the cable.Pull enough cable through the connector to get to the position of the light, plus a few feet of extra cable.Find the ceiling support beam closest to the desired light position.Lean a junction box against the edge of the beam and place it on the dry wall below.Trace the outline of the junction box with a pencil on the dry wall and cut the dry wall along the line with a key hole saw.Pass about 12 inch of the cable through the hole from the socket, and then use the mains nail and hammer to fix the cable to the top of the ceiling beam along the desired path.Back to the outlet box, tighten the screws on the cable clamp on the back of the outlet box and fix the two wires in the box.Cut off the cable from the roller with a pair of electric pliers, allowing about 6 inch of the cable to extend from the outlet box.Remove the outer sheath from the cable with a tool knife, and then peel off about 3/4 of the insulation from the tip of the black and white wire with a stripping machine.Bend a loop at the bare end of the black and white wire and wrap the white wire around the opening terminal on the same side of the socket as the existing white wire.Tighten the screw, fix the wire to the terminal, then tighten the black wire around the opening Terminal opposite the outlet, which is located below the existing black wire.Finally, wrap the bare wire around the bare wire that has been connected to the ground screw on the socket.Insert the wire into the outlet box and fix the outlet box on the box with mounting screws.Replace the outlet cover and fix it with the cover screw.Put a ladder under the ceiling opening.Remove a hole cover on the junction box and feed 6 inch of the cable from the hole in the ceiling through the hole on the junction box.Tighten the clamping screw to secure the cable in the box.Push the wire behind the connecting box into the hole in the ceiling.Adjust the position of the junction box so that the edge of the opening side of the box is flush with the bottom edge of the drywall.Install the junction box on the support beam adjacent to the opening if 2-Inch wood screw using electric drill.Peel off the outer sheath from the cable with a tool knife, and then use the stripping machine to peel off the insulation of 1/2 from the black and white wires.Find the mounting bracket from the hanging fixture and connect it to the junction box with two mounting screws.Screw the nipple into the center of the mounting bracket, and then screw the coupling of the hanging fixture into the nipple to hang the lamp.Wrap the bare wire around the green ground screw on the mounting bracket and tighten the screw with a screwdriver.Connect the black line on the junction box to the black line on the fixture and fix the tip of the wire with the wire nut.Repeat the process with two white lines.Slide the wire into the junction box above the mounting bracket and raise the canopy of the hanging lamp to cover the junction box.Screw the coupling under the canopy and fix the canopy on the mounting nipple.Install the necessary number of bulbs on the fixture and fix the globe.Turn the breaker on to the socket and test the light by pulling the chain to turn the light on and off.
